LPMS-IG1W: Ultra Low-Noise 9-Axis IMU / AHRS with Wi-Fi communication
The LPMS-IG1W is a high-performance 9-axis inertial measurement unit (IMU) and AHRS (attitude and heading reference system) with built-in Wi-Fi connectivity. Designed for wireless applications in robotics, AGVs, and embedded systems, it offers ultra-low-noise orientation and motion tracking in a compact, IP67-rated waterproof housing.
Fusing data from three low-noise gyroscopes, a 3-axis accelerometer, and a magnetometer, the sensor delivers accurate, low-drift 3D orientation data in real-time. It also includes a second high-speed gyroscope (up to 2000 dps) for dynamic use cases, with a selectable output mode.
The Wi-Fi interface allows flexible integration into wireless networks. Data access and parameter configuration are supported via IG1-Control software and SDKs for Windows, Linux, and embedded systems.
Key Features:
9-axis IMU / AHRS with ultra-low-noise gyroscopes
Wi-Fi interface for wireless connectivity
Dual gyroscopes: 400 dps + 2000 dps (selectable)
IP67-rated waterproof aluminum housing
Real-time 3D orientation and motion output
Ideal for wireless robotics, AGVs, and embedded systems
IG1-Control software + SDKs for Windows / Linux
See the LPMS-IG1W product pages at LP-RESEARCH for more detailed information.
Package details
1 x LPMS-IG1P CAN sensor
2 x Waterproof cables
1 x GPS antenna
1 x User guide card
1 x Warranty service (1 year)
NOTE: Import duties, taxes, and charges are not included in the item price or shipping cost. Please contact us for orders over 50 pieces.
